PATRIOTcarHAULER

Standard Features

4 Wheel Electric Brakes

Rust Inhibiting Chassis Protection by Z-Tech

Painted Tongue, Roof Bows and Area Around Door Openings

White Spoke 15" Wheels

Triple Tube A-Frame Draw-Bar w/ 2-5/16 Coupler

2000 Lb. Tongue Jack

3/4" Plywood Floor, Painted

3/8" Plywood Lined Interior Walls

Aluminum Fenders

102" Wide-Body Standard

Beavertail

Steel Frame Cross-Members @ 16" O.C.

Steel Sidewall Posts @ 16" O.C.

Steel Roof Bows @ 24" O.C.

.030 Smooth Aluminum Exterior

Roof Wrap White or Black

Seamed Galvalume Roof

Rear Ramp Door with Spring Assist and Flap

Zinc-Plated Cam-Bar Locks

36" Side Cargo Door w/ Steel Frame Stepwell

Breakaway Switch

Safety Chains and Hooks

Bargman / Glo-Brite Lighting DOT Standards

7 Way Male-Connector

Optional Patriot Package

Radial Tires

24" Stoneguard

(1) Non-powered Roof Vent

(2) 12 Volt-Dome Lights & Wall Mounted Switch

(4) 5,000 lb. Recessed D-Rings

Upgrade to 48" Side Door

PATRIOT SPECIFICATIONS

PAC8520TA2 PAC8524TA2 PAC8524TA3

Overall Length 24' 28' 28'

Width 8' 6" 8' 6" 8' 6"

Height 8' 6" 8' 6" 8' 6"

Interior/Box Length 20' 5" 24' 5" 24' 5"

Width/BWW 8' /81" 8' /81" 8' /81"

Height 6' 8" 6' 8" 6' 8"

Rear Door Ramp Ramp Ramp

Width 7' 6" 7' 6" 7' 6"

Height 6' 2" 6' 2" 6' 2"

Hitch Weight 300 lbs. 350 lbs. 350 lbs.

Hitch Height 19" 19" 19"

Ball/Pin Size (adj.) 2 5/16 " 2 5/16 " 2 5/16 "

Platform Height 19" 19" 19"

G.A.W.R. 7000 lbs. 7000 lbs. 10,400 lbs.

G.V.W.R. 7000 lbs. 7000 lbs. 9990 lbs.

Curb Weight 3200 lbs. 3950 lbs. 4650 lbs.

Payload Capacity 3800 lbs. 3050 lbs. 5790 lbs.

Axles 3500 lbs. 3500 lbs. 5200 lbs.

Brakes Electric Electric Electric

Tires ST205/75R15 ST205/75R15 ST225/75R15

Wheels 5 Bolt 5 Bolt 6 Bolt

Frame 6" I-Beam 6" I-Beam 6" I-Beam

Floor(16" O/C) 3/4" Plywood 3/4" Ply. /16" O/C 3/4" Ply. /16" O/C

Walls (16" O/C) 3/8" Plywood 3/8" Plywood 3/8" Plywood

PAC 8.5X20' $. PAC 8.5X24'TA2 $.

FACTORY PICKUP BRISTOL, INDIANA 47362

PAC 8.5X24'TA3 $. PAC 8.5X28'TA3 $.

6-14-2006 subject to change

TA2 IS 2 3500LB AXLES 7000 GVW TA3 IS 2 5200LB AXLES 9900 GVW
